UnoShaper Surfboards CNC.
Shape the most precise surfboards with UnoShaper CNC, a numerically controlled machine using CAD/CAM technology that combines speed and precision at a reasonable cost. Since 2010, it is the first surfboard CNC carving machine made in Spain.
The world of surfing has also evolved towards CAD/CAM. A good shaper needs a good pre-shape machine.
|Modelo UnoShaper CNC|
|Work area up to:||11 ft, 3420x1000x500 mm|
|14 ft, 4330x1000x500 mm|
|16 ft, 4620x1000x500 mm|
|Maximum speed:||15000 mm/min|
|Mandrino Mill Cutter:||high speed 1500 W|
|Rotation clamp mounts for bow and stern:||Yes|
|Fixation System:||Yes, with 6 vacuum cups|
|Vacuum pump:||Yes, three-phase or single-phase|
|3D laser scanner:||Yes|
|PC with CNC software:||Yes|
Due to our structure as a company being small, our prices can also be low, being more competitive and agile than the big fish.
We allow customizing our machines, something that other companies do not offer because it is very expensive.
We can design and manufacture machines that do not exist on the market, and we are part of a large business group that supports us.
It is the process of computer design. The shaper designs a table in a CAD program like Shape3DLite (free). During learning, it is helpful to use table models made by other shapers and modify them according to the taste of the shaper. Shape3D has an extensive Warehouse where you can download table models. The UnoShaper CNC can work with all CAD/CAM programs, but we recommend Shaper3D. You can start designing your tables with Shape3DLite (free); you can download it at this link: Shape3D
During the CAM process, the type of machine to be used, the diameter of the cutter, number of passes, cutting speed, and other parameters must be specified; that way, the CAM program generates the cutting files that the CNC machine will read for carving the correct form. The CAM process ends when the cut files are generated.
It is in the CNC process that the carving of the table is carried out. The cutting files generated in the CAM process make the machine move according to the proper trajectories to generate the designed shape in the CAD part. During this phase, it is necessary to correctly position the table and adjust the origin of the machine.
The UnoShaper CNC has its own EtherCAT-based control on Linux operating system and can read any G code from any CAM software.
